Sealing plug
Item no:
Got interested?
- Plastic plug with cross-head screw and seal ring
- After installation, the premounted seal ring reliably prevents moisture from penetrating into the component through the drill hole
Especially suitable for
- Anchorages in concrete, solid bricks, sand-lime bricks and other high-strength building
materials
With neoprene seal
| Art. no. | Dimensions [mm] | Drive | PU |
| Stainless steel A2 | |||
| 200050 | 6,0 x 30 | PZ 2 | 200 |
| 200051 | 6,0 x 40 | PZ 2 | 200 |
| 200052 | 6,0 x 50 | PZ 2 | 100 |
| 200053 | 6,0 x 60 | PZ 2 | 100 |
| Stainless steel, copper | |||
| 200040 | 6,0 x 30 | PZ 2 | 200 |
| 200041 | 6,0 x 40 | PZ 2 | 200 |
| 200042 | 6,0 x 50 | PZ 2 | 100 |
| 200043 | 6,0 x 60 | PZ 2 | 100 |
| Art. no | Type | Plug | Nail | Seal ring | Plug | Nail | Drill Ø subsurface |
min. Drill hole depth DHD |
min. Plug insertion depth ID |
max. Drill Ø in attached part |
max. Attachment thickness AT |
| Ø [mm] | Length [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | |||||
| 200050 | Stainless steel A2 | 6 | 4 | 15 | 30 | 35 | 6 | 35 | 25 | 6 | 5 |
| 200051 | Stainless steel A2 | 6 | 4 | 15 | 40 | 42 | 6 | 35 | 25 | 6 | 15 |
| 200052 | Stainless steel A2 | 6 | 4 | 15 | 50 | 52 | 6 | 35 | 25 | 6 | 25 |
| 200053 | Stainless steel A2 | 6 | 4 | 15 | 60 | 62 | 6 | 35 | 25 | 6 | 35 |
| 200040 | Stainless steel, copper | 6 | 4 | 15 | 30 | 35 | 6 | 35 | 25 | 6 | 5 |
| 200041 | Stainless steel, copper | 6 | 4 | 15 | 40 | 42 | 6 | 35 | 25 | 6 | 15 |
| 200042 | Stainless steel, copper | 6 | 4 | 15 | 50 | 52 | 6 | 35 | 25 | 6 | 25 |
| 200043 | Stainless steel, copper | 6 | 4 | 15 | 60 | 62 | 6 | 35 | 25 | 6 | 35 |
