Impact rivets
Item no:
Aluminium rivet body/stainless-steel mandrel
Got interested?
Impact fastening of
- Aluminium, sheet-metal, wall-end and roof-edge profiles
- Chimney flashing, wall coping
- Skylights, roof gullies, roof hatches, smoke extractors, flues
- Moisture-proof roofing sheets, flat-roof end profiles
- Linings and membrane connections for swimming pools
- Flange fastenings
- Frames, door and window frames
- Battens, insulation material
- Floor coverings and much more
| Art. no. | Shaft Ø rivet length [mm] | Drill Ø [mm] | max. Attachment thickness [mm] | PU |
| 111246 | 4,8 x 16 | 5,0 | 11,0 | 200 |
| 111247 | 4,8 x 20 | 5,0 | 15,0 | 200 |
| 111248 | 4,8 x 26 | 5,0 | 20,0 | 200 |
| 111249 | 4,8 x 30 | 5,0 | 25,0 | 200 |
| 111250 | 4,8 x 35 | 5,0 | 30,0 | 200 |
| 111251 | 1 4,8 x 40 | 5,0 | 35,0 | 200 |
| 111252 | 4,8 x 50 | 5,0 | 45,0 | 200 |
| 111253 | 5,0 x 20 | 5,0 | 5,0 | 200 |
| 111254 | 5,0 x 30 | 5,0 | 15,0 | 200 |
| 111260 | 5,0 x 40 | 5,0 | 25,0 | 200 |
